R630 Dual Vaporizers Veterinary Anesthesia Machine

  • R630 with double vaporizers was developed according to the requirement of veterinary clinics. Suitable for clinical anesthesia for dogs, cats, pigs, monkeys, rodents, reptiles, birds, etc.
  • Advantages

1) One machine, two options: dual evaporators meet various anesthesia needs, providing flexible anesthesia scheme and high quality
2) No drug mixing: “non-return” parallel structure to avoid drug mixing
3) Leak-proof and error-proof: Easy Fill to avoid leakage and wrong anesthetic filling

This model is no longer available for sale. Click to view more models


“We have received the anesthesia machine and we are using it with our students and colleagues in our post-degree program.
The device works fantastically well. The ventilator is very sensitive and adapts well to small patients, which is always important. It is super intuitive and very easy to control. Additionally, the absorbent filter for ISO makes it optimal for use in spaces without the “gas-exit” as in our case the X-ray or tomography rooms.”
/Dr.Pablo Eotero
/DVM, PHD. Professor in charge of the department of anesthesiology
/Faculty of Veterinary Science., UBA


“We got RWD anesthesia machine and the ventilator 2 months ago at #WASAVA conference.
The machine was easy to assemble and use.
The machine is working fine and very easy to switch from nonbreathing to breathing circuit with one switch.
The ventilator can be used from the smallest to the largest companion animal.
We are happy with both the machine and the ventilator and have no complaints.”

/Dr. Padmini Makkapati
Waterloo West Animal Hospital


“First in comparison to several other anesthesia machines the good workmanship and the thoughtful details of the R620-S1 have convinced us.
or two months we have now been using the intelligent ventilator R419 and we are really excited about it. It offers all ventilation modes like volume controlled, pressure controlled and assisted ventilation and the clear layout of the display makes setting easy.”

/Dr.Heinrich Koddebbusch
Der Narkosetieraerzt

Technical Specifications

  • Features
  • Technical Parameters
  • Model Information

Dual vaporizers two anesthesia solutions optional
“Non-return” parallel structure to avoid drug mixing
Easy Fill to avoid leakage and wrong anesthetic filling
Excellent user experience with APL vale, circuit switch and rail-mounted CO₂ absorber
Good waste gas scavenging system
Complete function with both breathing and non-rebreathing circuits

  • Double vaporizer design, users can quickly switch as demand
  • Applicable to animals that weight within 100kg
  • APL valve can be closed quickly with one button
  • 1 to 4 L/min O2 flowmeter
  • With oxygen flush function at a speed of 10L/min;
  • 2100cc CO2 absorber
  • Dual-channel flowmeter is optional
  • Work temperature:10-35℃
Cat No. Description Remarks
R630-A R630 Series Mounting Assembly with O2 Flowmeter (0.1-4LPM)_EN
R5832S Vaporizer for I- Easy Fill- Cagemount
R583S Vaporizer for S- Easy Fill- Cagemount
R580-IO Vaporizer Endcaps (1 pair) 2 pair included
R510-31 Gas Filter Canister, Large
R600-ET Cuffed Endotracheal Tubes (1 set)
R600-NL-0.5L Reusable Non Latex Breathing Bag, 0.5L
R600-NL-1L Reusable Non Latex Breathing Bag, 1L
R600-NL-2L Reusable Non Latex Breathing Bag, 2L
R-BC-DL Breathing Circuit Duo-limb, 22mm(M)/15mm(F), 1.5m
R-NBC-F(JR) Mapleson F Non-rebreathing Circuit (Jackson-Rees)
R-CT-18 Corrugated Tube – ID 22.0mm, L1.2m
