R520 Portable Anesthesia Machine

  • The Enhanced Anesthesia Machine is designed for safe, simple, and controllable inhalation anesthesia for rat, mouse, rabbit, hamster and Guinea pig. It is protable upgraded from R540 Enhanced Anesthesia Machine. places all your anesthesia equipment including vaporizer, flowmeter, induction chamber, air-pump, gas evacuation apparatus, canister on one sleek, compact post, which allows easy and convenient transportation of the whole unit.

Technical Specifications

  • Feature
  • Technical Specification
  • Order Information

• Integration of the draw, Save space, easy to move
• Design generous, beautiful appearance, simple operation
• Accurate oxygen flow meter, Flow control range: 0-4L/min available
• High accuracy vaporizer (Each one has an independent test report)
• Gas toggle switch, button switching gas path, more than 100,000 times of service life.
• Quick oxygenation switch to remove residual anesthetic mixture in the tube or anesthesia induction chamber.
• Oxygen or air can be chosen as gas supply.
• Easy Fill, Pour Fill, Key Fill for adding drugs is optional.
• Can be upgraded into portable anesthesia machine to save space and facilitate movement
• The double flowmeters installation space on the back to meet the simultaneous
0.1-1L/min oxygen flowmeter, anesthesia for two animals

• Applicable to rats, mice, hamsters, guinea pigs, rabbits, cats and other animals within 7kg
• 0.1 to 4 L/min O2 flowmeter
• 10L/min O2 flush
• Three kinds of filling type vaporizer is optional-Pour Fill , Easy Fill and Key Fill
• Concentration range: Isoflurane: 0-5%, sevoflurane: 0-8%, Accuracy range is low than 10%
• Work temperature:10-35℃

Cat No. Product Description Configuration Remarks
R520IE Movable Small Animal Anesthesia Machine-Isoflurane, Easy Fill, 0-4L ● Contains connection
tubing for
mask&induction
chamber
R520IP Movable Small Animal Anesthesia Machine-Isoflurane, Pour Fill, 0-4L ●
R520SE Movable Small Animal Anesthesia Machine-Sevoflurane, Easy Fill, 0-4L ●
R520SP Movable Small Animal Anesthesia Machine-Sevoflurane, Pour Fill, 0-4L ●
